SS 304 Sheets & Plates
Giriraj Impex stocks, supplies and exports SS 304 sheet and plate to ASTM A240 / ASME SA240 grades 304 and 304L, dual certified where required. We supply SS 304 sheets from approved mills in cold-rolled thicknesses with 2B, BA, No. 4 and hairline finishes, and SS 304 plates hot rolled, annealed and pickled, with mill test certificates.
SS 304 sheet and plate are the most widely used stainless flat products – for tanks, vessels, food and dairy equipment, kitchens, architectural panels and general fabrication – wherever good corrosion resistance and formability are needed and chloride exposure is low.
Specifications
| Item | Sheet | Plate |
|---|---|---|
| Standard | ASTM A240 / ASME SA240; ASTM A480 general requirements | |
| Grades | 304 (S30400), 304L (S30403), dual certified 304/304L; 304H on request | |
| Production | Cold rolled | Hot rolled |
| Thickness | Below 4.76 mm | 4.76 mm and above |
| Finishes | 2B, BA, No. 4, hairline, No. 8 mirror | Hot rolled, annealed and pickled |
| Protection | PVC film on request | – |
| Documents | Mill test certificate (MTC); third-party inspection on request | |
Chemical composition and mechanical properties
| Grade | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | N |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | S30400 | 0.07 | 2.00 | 0.045 | 0.030 | 0.75 | 17.5–19.5 | 8.0–10.5 | – | 0.10 |
| 304L | S30403 | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 17.5–19.5 | 8.0–12.0 | – | 0.10 |
| 316 | S31600 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 | 0.10 |
| 316L | S31603 | 0.030 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 | 0.10 |
Other elements and footnotes as given in the standard.
| Grade | Tensile strength min, MPa (ksi) | Yield strength min, MPa (ksi) | Elongation in 50 mm min, % | Hardness max, HBW / HRB |
|---|---|---|---|---|
| 304 | 515 (75) | 205 (30) | 40 | 201 / 92 |
| 304L | 485 (70) | 170 (25) | 40 | 201 / 92 |
| 316 | 515 (75) | 205 (30) | 40 | 217 / 95 |
| 316L | 485 (70) | 170 (25) | 40 | 217 / 95 |
Values for annealed material.
Background and equivalents are on the SS 304 / 304L page.
SS 304 sheet and plate weight chart
Theoretical weights below use a density of 7.93 g/cm³, commonly used for 304 (7.93 kg per square metre per millimetre of thickness). Actual weights vary with thickness tolerance; use the weight calculator for other sizes.
| Thickness, mm | kg per m² | Sheet 1250 × 2500 mm, kg | Sheet 1500 × 3000 mm, kg |
|---|---|---|---|
| 0.5 | 3.96 | 12.4 | 17.8 |
| 0.8 | 6.34 | 19.8 | 28.5 |
| 1 | 7.93 | 24.8 | 35.7 |
| 1.2 | 9.52 | 29.7 | 42.8 |
| 1.5 | 11.89 | 37.2 | 53.5 |
| 2 | 15.86 | 49.6 | 71.4 |
| 3 | 23.79 | 74.3 | 107.1 |
| 4 | 31.72 | 99.1 | 142.7 |
| 5 | 39.65 | 123.9 | 178.4 |
| 6 | 47.58 | 148.7 | 214.1 |
| 8 | 63.44 | 198.2 | 285.5 |
| 10 | 79.30 | 247.8 | 356.8 |
| 12 | 95.16 | 297.4 | 428.2 |
| 16 | 126.88 | 396.5 | 571.0 |
| 20 | 158.60 | 495.6 | 713.7 |
| 25 | 198.25 | 619.5 | 892.1 |
Choosing finish and thickness
For process and storage equipment, 2B sheet and hot-rolled plate are standard. For kitchens, food counters, lifts and panels, No. 4 or hairline finishes hide fingerprints and light scratches; BA and mirror finishes are used for decorative and reflective work. Where sheets will be welded into tanks or vessels, 304L or dual-certified 304/304L avoids sensitisation at the welds. Thicker plates for vessels and tube sheets are often ordered with ultrasonic testing. For seawater or chloride splash, choose SS 316 sheets and plates instead.
Ordering SS 304 sheets and plates
Please give the grade, thickness, finish (one or both sides), sheet or plate size, quantity, any protective film, and supplementary tests or inspection. Sheets and plates are packed flat on pallets with interleaving for polished finishes, and each delivery is checked against the mill test certificate before dispatch.
Sheet and plate quality
Every sheet and plate is supplied by the mill solution annealed and with a surface finish that meets ASTM A480. Cold-rolled sheets are flat, with close thickness tolerance, so they suit laser cutting and precision bending. Hot-rolled plates have wider thickness tolerances and a dull pickled surface and are intended for fabrication of heavy equipment. Mill edges can be slightly irregular and are trimmed where needed. Each sheet or bundle carries the mill marking with grade, specification, heat number and dimensions, which should be kept on offcuts so material can be traced in the workshop.
Stainless sheets should be stored indoors, off the floor and away from carbon steel, and handled with clean gloves and lifting equipment to avoid scratches and iron contamination on decorative finishes.
Applications and related products
SS 304 sheets and plates are used for storage and process tanks, dairy and brewery vessels, food machinery, commercial kitchens, hospital and laboratory equipment, lifts and escalators, architectural cladding, signage and general fabrication. All stainless flat products are on the stainless steel sheets and stainless steel plates pages, and other materials on the sheets and plates pages. In the same grade we also supply SS 304 pipes and SS 304 round bars.
Frequently Asked Questions
ASTM A240 (ASME SA240) covers SS 304 and 304L plate, sheet and strip. General requirements for tolerances and finishes are in ASTM A480.
Using a density of 7.93 g/cm³, SS 304 weighs about 7.93 kg per square metre for each millimetre of thickness. A 1250 × 2500 mm sheet 1 mm thick weighs about 24.8 kg.
Under ASTM A480, material under 4.76 mm thick is sheet (usually cold rolled with finishes such as 2B) and 4.76 mm and over is plate (usually hot rolled, annealed and pickled).
No. 4 (brushed) or hairline finishes are normally used for kitchen and food-service equipment because they are easy to clean and hide minor marks.
Yes, in normal inland atmospheres. In coastal or polluted environments SS 316 is recommended, as 304 can tea-stain and pit where chlorides deposit.
Yes. Polished and bright sheets are supplied with PVC protective film on request to protect the finish during handling and fabrication.
